Description:
Upgrades on the 6400 & 6800 model panel saws compared to our H-Series Panel Saws include:
An upgraded, worm drive motor providing greater longevity.
1/64″ straight and square cutting tolerance compared to 1/32″ on our H-Series Machines that’s made possible by additional bearings.
Additional steel welded at a diagonal plane adding significant weight to the frame.
A weighted pulley system for pulling the saw motor up and down the guide tubes vs a spring loaded counter balance.
Additional bearings within the motor providing a tighter cutting tolerance.
Aluminum material rollers.
Standard Equipment:
3 Hp worm driven heavy-duty saw motor.
10 ft. welded steel frame.
Chrome-plated 1 3/4″ guide tubes.
8 Nylatron roller bearing systems.
Adjustable vertical and horizontal rulers.
Quick change from vertical to horizontal cutting.
Thin material pressure guard.
Solid aluminum material rollers.
Enclosed counterweight system.
Integrated dust collection bonnet.
TUV certified to UL/CSA standards.
